3D 90° spatial corner connector No. 2, T:5mm ( Hot Dip Galvanized )

3D 90° spatial corner connector No. 2, T:5mm ( Hot Dip Galvanized )

3D 90° spatial corner connector No. 2, T:5mm ( Hot Dip Galvanized )

3D 90° spatial corner connector No. 2, T:5mm ( Hot Dip Galvanized )

3D 90° spatial corner connector No. 2, T:5mm ( Hot Dip Galvanized )

Code:

ACB-906 HDG

Unit: Piece

Basic features

Designed for 3D corner connection of three C-profiles (strut channels) at 90° angles. The design wraps around a vertical post and forms a corner platform for two mating horizontal profiles routed perpendicularly from above. Ensures precise geometric positioning and high strength of the 3D node. Hot-dip galvanized (Hot Dip Galvanized) protective coating guarantees high corrosion resistance when operated in high humidity and aggressive environments.

Specifications:

Steel thickness: 5.0 mm

Overall flange length: 90 mm

Body width: 48 mm

Flange width: 40 mm

Hole diameter: 14 mm

Protective coating: Hot-dip galvanizing (HDG)

Weight: 0.280 kg / pc.
