Horizontal Bend ( Adjustable )W: 500 mm · H: 40 mm · T: 1,0 mm · Hot Dip Galvanized

Name: Horizontal Bend ( Adjustable ) W500mm H40mm T1,0mm Hot Dip Galvanized
SKU: 901H-4A-50 HDG

Code:

901H-4A-50 HDG

Unit: Piece

Basic features

Width

Height

Thickness

Coating

The adjustable bend allows the cable tray to change direction horizontally at different angles. It has a side height of 40 mm and a base width of 500 mm. The sheet thickness is 1 mm. The product is available in Pre-Galvanized (Pre Galvanized) and Hot-Dip Galvanized (Hot Dip Galvanized) finishes.

Datasheet

NOTES:

1- As standard, “A and B” dimensions are manufactured equal;
Upon request, “Dimension B” can be changed by reduction.
2- Other radii can be manufactured.
3- Production in different sheet thicknesses is available.
4- Please specify the product code and coating type in your orders.
