Inside Vertical Bend 90˚ (Fixed Type)W: 50 mm · H: 40 mm · T: 1,2 mm · Hot Dip Galvanized

Name: Inside Vertical Bend 90˚ (Fixed Type) W50mm H40mm T1,2mm Hot Dip Galvanized
SKU: 705-4A HDG

Code:

705-4A HDG

Unit: Piece

Basic features

Width

Height

Thickness

Coating

The fixed internal vertical bend is used to change the direction of the cable tray vertically. This accessory provides a smooth upward or downward transition. It is compatible with cable trays 50 mm wide and 40 mm high. The sheet thickness is 1.2 mm. The product is available in Pre-Galvanized (Pre Galvanized) and Hot-Dip Galvanized (Hot Dip Galvanized) finishes.

Datasheet

NOTES:
1- As standard, “A and B” dimensions are manufactured equal;
Upon request, “Dimension B” can be changed by reduction.
2- Other radii can be manufactured.
3- Production in different sheet thicknesses is available.
4- Please specify the product code and coating type in your orders.
