    U Hanging Support No. 3, T:2mm ( Hot Dip Galvanized )

    U Hanging Support No. 3, T:2mm ( Hot Dip Galvanized )
    U Hanging Support No. 3, T:2mm ( Hot Dip Galvanized )
    U Hanging Support No. 3, T:2mm ( Hot Dip Galvanized )
    U Hanging Support No. 3, T:2mm ( Hot Dip Galvanized )
    Code:
    A3-2-2B-E HDG
    Unit: Piece
    Basic features
    Coating

    Ceiling bracket (base plate/support shoe) designed for mounting U-shaped profiles and creating load-bearing structures for cable runs, utility lines, and suspension systems to ceilings or horizontal slabs. Features a zinc coating and is corrosion-resistant.

    Datasheet

    Specifications:

    Steel thickness: 2 mm
    Color: Light gray
    Model/Design: Ceiling mount
    Width: 58 mm
    Height: 84 mm
    Surface protective coating: Hot Dip Galvanized
    Length: 90 mm
    Material: Steel

    Download Now
    A3-1-40-15 HDG
    A3-1-40-15 HDG
    Welded ceiling mounting bracket, L:400mm T1,5mm ( Hot Dip Galvanized )
    Unit: Piece
    A3-1-80-15 HDG
    A3-1-80-15 HDG
    Welded ceiling mounting bracket, L:800mm T1,5mm ( Hot Dip Galvanized )
    Unit: Piece
    A3-3-20 PG
    A3-3-20 PG
    Profile mounting bracket, L:200mm T1,5mm ( Pre Galvanized )
    Unit: Piece
    A3-3-60 HDG
    A3-3-60 HDG
    Profile mounting bracket, L:600mm T2mm ( Hot Dip Galvanized )
    Unit: Piece
